Model 309 Utility application shown with a PC connected to a physical Model 309 using the standard EIA-232-E (aka RS-232) serial port. All readouts mirror the real instrument, and all controls except main power and current adjust can be invoked with the mouse (the mouse is shown positioned over the Start Test button for starting and stopping a test).
Click here for a higher resolution version of this image.
Click here to go to
the network section of the Owner's Manual.
